Brief Introduction:
Brand: Hitachi
Model: 60-5G
Year of Manufacture: 2013
Engine Power: 42.4 kW (57.6PS)
Location:Nanning, China
Price EXW Nanning China $10716
Power: Conventional Power
Manufacturer: Joint Venture/Imported
Bucket: Backhoe
Tonnage: 6 tons
Operating Weight: 5850 kg
Bucket Capacity: 0.22 m³
Boom Length: 3.49 mm
Stick Length: 1.6 mm (Reinforced Version)
Origin: Hefei, Anhui
Swing Speed: 9.3 rpm
Travel Speed: 2.5/4.5 km/h
Grading Ability: 70/35°
Ground Pressure: 33 kPa
Bucket Digging Force: 41.4 kN
Stick Digging Force: 28.4 kN
Engine Model: Isuzu CC-4JG1
Rated Power (kW/rpm): 40.5/2100
Displacement (L): 3.059
Number of Cylinders: 4
Cooling Method: Water Cooling
Operating Type: Direct Injection
Main Pump Type: Variable Displacement
Piston Pump ×2 + Gear Pump ×2 Travel
Hydraulic Motor Type: Variable Displacement
Swashplate Piston Motor ×2
Rotary Hydraulic Motor Type: Axial Piston Motor ×1
Main Overflow Setting Pressure (MPa): 24.5
Fuel Tank (L): 120
Hydraulic Oil Tank (L) 61 (Full tank 95)
Engine oil change volume (L) 12
Overall transport length (mm) 6060
Overall transport width (mm) 2060
Overall transport height (mm) 2470
Cabin height (mm) 2470
Track ground contact length (mm) 2000
Total track length (mm) 2480
Track shoe width (mm) 400
Total track width (mm) 2000
Track gauge (mm) 1600
Minimum ground clearance (mm) 310
Counterweight ground clearance (mm) 620
Minimum turning radius of front working device (mm) 2510
Rear turning radius (mm) 1650
Maximum digging radius (mm) 6250
Maximum digging depth (mm) 3850
Maximum digging height (mm) 5800
Maximum unloading height (mm) 4080
Maximum vertical digging depth (mm) 3300
Bulldozer blade lifting or pushing depth (mm) 430/400
