Excavator For Sale Liugong 933E Used Digger

📧 Leave us a message

---

Original Factory Parameters Of The Used Hitachi 60-5G:

Power source: Traditional power
Manufacturer: Domestic
Bucket: Backhoe
Tonnage: 33 tons
Operating weight: 31800 kg
Bucket capacity: 1.4 m³
Boom length: 6200 mm
Stick length: 3050 mm

Performance:

Slewing speed (rpm): 10.3
Travel speed (km/h): 5.5/3.0
Climbing ability (%): 35°
Ground pressure (kPa): 60
Bucket digging force (kN): 187/203
Hoist digging force (kN): 137/149
Maximum traction force (kN): 300

Power System:

Engine Model: Cummins QSB7
Rated Power (kW/rpm): 169/2050
Maximum Torque (N.m): 895/1300
splacement (L): 6.7
Number of Cylinders: 6 Bore × Stroke (mm): 107*124
Cooling Method: Water Cooling
Operating Mode: Turbocharged, Air-to-Air Intercooled, High-Pressure Common Rail, Electronic Direct Injection

Hydraulic System:

Travel hydraulic circuit (MPa) 34.3
Rotary hydraulic circuit (MPa) 26.2 Oil
capacity: Fuel tank (L) 520
ydraulic oil tank (L) 195
Hydraulic system (L) 360

Fuel Capacity:

Fuel tank (L) 520
Hydraulic oil tank (L) 195
Hydraulic system (L) 360

Main dimensions:

Total transport length (mm): 10650
Total transport width (mm): 3190
Total transport height (mm): 3525
Track width (mm): 600
Track gauge (mm): 2590
Minimum ground clearance (mm): 500
Minimum turning radius of the front working device (mm): 4040

Operating range:

Maximum digging radius (mm): 10653
Maximum digging radius at the stopping face (mm): 10453
Maximum digging depth (mm): 7300
Maximum digging height (mm): 10300
Maximum unloading height (mm): 7265
Maximum vertical digging depth (mm): 6216
